Customize Quick Menu

You can use a customize the quick menu with a custom list of tools.

Customize quick menu in Xamarin.Android

This tutorial only applies to Xamarin.Android.

It is possible to customize the quick menu by overriding the default menu resource XML files, or by creating your own.

Add/remove item to the quick menu

It is possible to programmatically modify the quick menu by calling methods to add and remove items.

The following example will customize the quick menu for the Square tool by using the ShowQuickMenu event and adding a link button. Menu entries can be moved around and removed as well.

1. Add a menu entry to the ids.xml in Resources/values to identify it:

XML

<resources>
    ...

    <item name="qm_custom_link" type="id" />

    ...
</resources>

1. Create event handler for the ShowQuickMenu event, and add the code below to create a new QuickMenuItem and specify the order you would like for it to show:

C#

mPdfViewCtrlTabHostFragment.CurrentPdfViewCtrlFragment.ShowQuickMenu += (sender, e) =>
{
    if (e.Annot != null && e.Annot.Type == (int) Annot.Type.e_Square)
    {
        QuickMenuItem item = new QuickMenuItem(this, Resource.Id.qm_custom_link,
            QuickMenuItem.FirstRowMenu);
        item.SetTitle("Custom Link");
        item.SetIcon(Resource.Drawable.ic_link_black_24dp);
        item.SetOrder(3);
        List<QuickMenuItem> items = new List<QuickMenuItem>(1);
        items.Add(item);
        e.Quickmenu.AddMenuEntries(items);
    }
    e.Handled = false;
};

Java

    if (annot.getType() == Annot.e_Square) {
        QuickMenuItem item = new QuickMenuItem(MainActivity.this, R.id.qm_custom_link,
            QuickMenuItem.FIRST_ROW_MENU);
        item.setTitle(R.string.qm_custom_link);
        item.setIcon(R.drawable.ic_link_black_24dp);
        item.setOrder(3);
        ArrayList<QuickMenuItem> items = new ArrayList<>(1);
        items.add(item);
        quickMenu.addMenuEntries(items);
    }

The quick menu for the square tool will now have a link item at the 3rd (0 index) position like this:

Quickmenu items can be removed by calling the removeMenuEntries method in the QuickMenu class:

C#

mPdfViewCtrlTabHostFragment.CurrentPdfViewCtrlFragment.ShowQuickMenu += (sender, e) =>
{
    if (e.Annot != null && e.Annot.Type == (int) Annot.Type.e_Square)
    {
        QuickMenuItem item = new QuickMenuItem(this, Resource.Id.qm_custom_link,
            QuickMenuItem.FirstRowMenu);
        List<QuickMenuItem> items = new List<QuickMenuItem>(1);
        items.Add(item);
        e.Quickmenu.RemoveMenuEntries(items);
    }
    e.Handled = false;
};

Java

if (annot.getType() == Annot.e_Square) {
    QuickMenuItem item = new QuickMenuItem(MainActivity.this, R.id.qm_custom_link,
        QuickMenuItem.FIRST_ROW_MENU);
    ArrayList<QuickMenuItem> items = new ArrayList<>(1);
    items.add(item);
    quickMenu.removeMenuEntries(items);
}

---

Override menu resources

In this tutorial you will customize the quick menu for the Pan tool by overriding the default menu resource XML file in the Apryse SDK.

1. Create a menu resource XML file called pan.xml in your project's Resources/menu folder. This pan.xml file will automatically be used instead of the default one in the tools package. To override other quick menus, refer to the table below to determine the name of the menu resource file.
2. Add two items to you menu in pan.xml with the id attributes @+id/qm_free_text and @+id/qm_floating_sig:Here we use the ids @+id/qm_free_text and @+id/qm_floating_sig to override the Free Text and Signature menu items.Now, when you long-press on a blank space, you will see:

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:id="@+id/qm_free_text" android:title="@string/tools_qm_free_text" android:icon="@drawable/ic_annotation_freetext_black_24dp" />
    <item android:id="@+id/qm_floating_sig" android:title="@string/tools_qm_signature" android:icon="@drawable/ic_annotation_signature_black_24dp" />
</menu>

You can also create your own menu items by providing a unique id, or by overriding our other menu items using the menu ids defined in the tools package. You can learn more about handling custom menu item click events.

Quick menu resources

pan	Pan	Long press on blank space
text_select	TextSelect	Long press on text
annot_simple_shape	AnnotEdit	Single tap on Square, Circle, Line, Polygon, Polyline, Text
annot_free_text	AnnotEdit	Single tap on FreeText
annot_link	AnnotEdit	Single tap on Link
annot_signature	AnnotEdit	Single tap on signature (type: Annot.e_Stamp and custom field: Signature.SIGNATURE_ANNOTATION_ID)
annot_stamper	AnnotEdit	Single tap on Stamp(type: Annot.e_Stamp)
annot_file_attachment	AnnotEdit	Single tap on FileAttachment
annot_free_hand	AnnotEdit	Single tap on Ink
annot_general	AnnotEdit	Single tap on all other annotation types
annot_edit_text_markup	AnnotEditTextMarkup	Single tap on TextMarkup annotations
type	AnnotEditTextMarkup	Click quick menu item with id R.id.type
sig_field_image	DigitalSignature	Single tap on digital image signature
annot_edit_thickness	DigitalSignature	Click quick menu item with id R.id.thickness
sig_field_paths	DigitalSignature	Single tap on digital signature, or click on items in quick menu R.menu.annot_edit_thickness

Create your own quick menu

You can use quick menus in a ToolManager as well as in your application logic directly. By the end of this tutorial, you will be able to create your own quick menu.

1. First, add a menu resource XML file in your project's Resources/menu folder. For example, let's create a file called custom.xml.

By default, all menu items are placed in the first row of the quick menu. If you want to specify the location of a menu item, enclose the item inside a group with a group id from this list:

Group id	Location in quick menu
@id/qm_first_row_group	First row group id: all menu items inside this group will be displayed in the first row of the quick menu.
@id/qm_second_row_group	Second row group id: all menu items inside this group will be displayed in the second row of the quick menu.
@id/qm_overflow_row_group	Overflow list group id: all menu items inside this group will be displayed in the overflow menu list of the quick menu.

1. Add the following to custom.xml:

XML

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android">
    <group android:id="@id/qm_first_row_group">
        <item android:id="@+id/rectangle"
            android:title="@string/tools_qm_rectangle"
            android:icon="@drawable/ic_annotation_square_black_24dp" />
    </group>
    <group android:id="@id/qm_second_row_group">
        <item android:id="@+id/line"
            android:title="@string/annot_line"
            android:icon="@drawable/ic_annotation_line_black_24dp"/>
        <item android:id="@+id/free_text"
            android:title="@string/tools_qm_free_text"
            android:icon="@drawable/ic_annotation_freetext_black_24dp"/>
    </group>
    <group android:id="@id/qm_overflow_row_group">
        <item android:id="@+id/floating_sig"
            android:title="@string/tools_qm_signature"/>
        <item android:id="@+id/link"
            android:title="@string/annot_link"/>
    </group>
</menu>

You can also add a sub menu by specifiying it in the menu resource XML. For example, we can add an Oval menu item as a submenu under the Rectangle menu item by changing custom.xml to:

XML

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android">
    <group android:id="@id/qm_first_row_group">
        <item android:id="@+id/rectangle"
            android:title="@string/tools_qm_rectangle"
            android:icon="@drawable/ic_annotation_square_black_24dp" >
            <!-- Sub menu added to Rectangle menu item -->
            <menu>
                <group android:id="@id/qm_first_row_group">
                    <item android:id="@+id/oval"
                        android:title="@string/annot_circle"/>
                </group>
            </menu>
        </item>
    </group>
    <group android:id="@id/qm_second_row_group">
        <item android:id="@+id/line"
            android:title="@string/annot_line"
            android:icon="@drawable/ic_annotation_line_black_24dp"/>
        <item android:id="@+id/free_text"
            android:title="@string/annot_free_text"
            android:icon="@drawable/ic_annotation_freetext_black_24dp"/>
    </group>
    <group android:id="@id/qm_overflow_row_group">
        <item android:id="@+id/floating_sig"
            android:title="@string/tools_qm_signature"/>
        <item android:id="@+id/link"
            android:title="@string/annot_link"/>
    </group>
</menu>

For more information on defining an XML menu resource, see Defining a Menu in XML.

1. After adding the menu resource XML, initialize QuickMenu as follows:

C#

void InitQuickMenu(PDFViewCtrl pdfViewCtrl)
{
    var quickMenu = new QuickMenu(pdfViewCtrl);
    quickMenu.InitMenuEntries(Resource.menu.custom);
}

Java

    private void initQuickMenu(PDFViewCtrl pdfViewCtrl) {
        QuickMenu quickMenu = new QuickMenu(pdfViewCtrl);
        quickMenu.initMenuEntries(R.menu.custom);
    }

Kotlin

    private void initQuickMenu(PDFViewCtrl pdfViewCtrl) {
        QuickMenu quickMenu = new QuickMenu(pdfViewCtrl);
        quickMenu.initMenuEntries(R.menu.custom);
    }

Alternatively, if you want to customize menu items manually you can call QuickMenu.Inflate to prevent auto-initialization. Then after customizing the items, call QuickMenu.initMenuEntries to apply your changes:

C#

    void InitQuickMenu(PDFViewCtrl pdfViewCtrl) {
        var quickMenu = new QuickMenu(pdfViewCtrl);
        quickMenu.Inflate(Resource.Menu.custom);
        var quickMenuItem = (QuickMenuItem) quickMenu.Menu.FindItem(Resource.Id.rectangle);
        // Customize my quick menu item
        quickMenuItem.SetIcon(Resource.Drawable.my_custom_icon);
        quickMenuItem.SetTitle(Resource.String.my_custom_title);
        // Initialize quick menu
        quickMenu.InitMenuEntries();

Java

    private void initQuickMenu(PDFViewCtrl pdfViewCtrl) {
        QuickMenu quickMenu = new QuickMenu(pdfViewCtrl);
        quickMenu.inflate(R.menu.custom);
        QuickMenuItem quickMenuItem = (QuickMenuItem) quickMenu.getMenu().findItem(R.id.rectangle);
        // Customize my quick menu item
        quickMenuItem.setIcon(R.drawable.my_custom_icon);
        quickMenuItem.setTitle(R.string.my_custom_title);
        // Initialize quick menu
        quickMenu.initMenuEntries();
    }

Kotlin

    private fun initQuickMenu(pdfViewCtrl: PDFViewCtrl) {
        val quickMenu = QuickMenu(pdfViewCtrl)
        quickMenu.inflate(R.menu.custom)
        val quickMenuItem = quickMenu.menu.findItem(R.id.rectangle) as QuickMenuItem
        // Customize my quick menu item
        quickMenuItem.setIcon(R.drawable.my_custom_icon)
        quickMenuItem.setTitle(R.string.my_custom_title)
        // Initialize quick menu
        quickMenu.initMenuEntries()
    }

1. When you want to show the quick menu, set an anchor view that defines where the quick menu should appear by calling QuickMenu.SetAnchor(View)

C#

    private void ShowQuickMenu(QuickMenu quickMenu, View view) {
        quickMenu.SetAnchor(view);
        quickMenu.Show();
    }

Java

    private void showQuickMenu(QuickMenu quickMenu, View view) {
        quickMenu.setAnchor(view);
        quickMenu.show();
    }

Kotlin

    private fun showQuickMenu(quickMenu: QuickMenu, view: View) {
        quickMenu.setAnchor(view)
        quickMenu.show()
    }

The quick menu will automatically adjust its position to either the top or bottom of the anchor view, depending on the space available:

At this point, you should see the following when the quick menu is shown:

Without sub menu:

With sub menu:

Click events

Click events from your custom items will not be automatically handled by the Apryse SDK if the menu item id does not match any of the default ids defined in the tools package (located in the PDFViewCtrlTools\res\menu\ids.xml file). You will have to handle these events as described in this guide or by implementing DismissEvent:

C#

quickMenu.DismissEvent += (sender, e) =>
{
    // Get selected quick menu item
    var selectedMenuItem = quickMenu.SelectedMenuItem;
    // Provide functionality depending on the menu item selected
    // ...
}

Java

quickMenu.setOnDismissListener(new QuickMenu.OnDismissListener() {
    @Override
    public void onDismiss() {
        // Get selected quick menu item
        QuickMenuItem selectedMenuItem = quickMenu.getSelectedMenuItem();
        // Provide functionality depending on the menu item selected
        // ...
    }
});

Kotlin

quickMenu.setOnDismissListener {
    // Get selected quick menu item
    val selectedMenuItem = quickMenu.selectedMenuItem
    // Provide functionality depending on the menu item selected
    // ...
}
