Version 8.1.1 Changelog (February 17, 2021)

Version: 8.1.1.76966

Release Date: February 17, 2021

This release of Apryse's SDK for UWP adds Microsoft WinUI 2 library as a dependency of the UWP Tools SDK.

• [tools] [resources] All converters moved to pdftron.PDF.Tools.Converters namespace
• [tools] [resources] All command events moved to pdftron.PDF.Tools.Commands.Events namespace
• [tools] [dependency] Removed pdftron.UWP.Common.dll as a dependency

• [tools] [control] AnnotationCommandBar default height changed from 48px to 40px

Note: when editing area or perimeter a feedback value is displayed while dragging a vertice

• When editing ruler annotation is possible to calibrate it in order to change it's value and measurement unit

Note: Area Redaction allows to add an overlay text on the redacted region

Note: for more information on how to implement the Viewer Control please follow the guide here...

• [pdf] Added PDFDoc generator which allow to create Blank, Grid, Lined, Graph, Music, Dotted, and Isometric paper type
• [pdf] Added capability of applying OCR XML and JSON data to PDF
• [tools] Added RulerCreate / Ruler Annotation and Calibration feature
• [tools] Added AreaCreate / Area Annotation
• [tools] Added PerimeterCreate / Perimeter Annotation
• [tools] Added vertices editing for Advanced Shapes: Polygon, Polyline, Cloud, Area and Perimeter annotations.
• [tools] Added Area Redaction
• [tools] Added Text Redaction
• [tools] Marquee Zoom: Added missing property to Enable or Disable it on AnnotationToolbar
• [tools] [control] Added CropPopupControl
• [tools] [control] Added CustomColorPopupControl
• [tools] [control] Added OptimizePopupControl
• [tools] [control] Added PasswordPopupControl
• [tools] [control] Added QuickSettingsControl
• [tools] [control] Added ViewerControl
• [tools] [control] Thumbnail Viewer: added duplicate page command to the overlay page commands
• [tools] [control] Annotation Toolbar: Added Save option after adding an advanced shape considering the min points for polygon (3 pts) and polyline (2 pts)
• [tools] [control] Added FindTextDialog
• [tools] [control] Added OutlineDialog
• [tools] [control] Added PDFViewCtrlTabButtonControl
• [tools] [control] Added PDFViewCtrlTabControl
• [tools] [control] Added SaveAsNotification
• [tools] [control] Updated UI design of AnnotationPropertyDialog
• [tools] [utility] Added WindowsInfo as a helper class when using adaptive code
• [tools] [utility] Added MeasureUtils as a helper class when working with measurements tools
• [tools] [resources] Added glyph-icon.ttf with new icons design
• [tools] [dependency] Added Microsoft.UI.Xaml v2.5.0 (WinUI 2.5)

• [tools] Fixed crash when using FreeHand annotation with mouse and pen/stylus
• [tools] Fixed Marquee Tool not returning to Pan if setting is enabled
• [tools] Added Adaptive Code for old Windows SDK versions (FreeText and AnnotEdit)
• [tools] Fixed Polygon not adding filling color on creation
• [tools] Fixed Signature dialog hang if no signature was inserted
• [tools] Fixed annotation tool not properly switching between main and secondary menu on the annotation toolbar when resizing app
• [tools] Removed SelectionFlyout popup from RichText when editing FreeText annotation for not being supported
• [tools] Fixed crash when using AdvancedShapeCreate and a tentative of creation happens when no points have been selected
• [tools] Fixed missing fill color when creating Polygon, Cloud and Area annot
• [tools] [control] Fixed ThumbnailItem missing IsConvert property binding issue
• [tools] [control] Fixed ThumbnailItem missing IsConvert property binding issue

New class: PDFDocGenerator

• New method: static PDFDoc GenerateBlankPaperDoc(double, double, double, double, double)
• New method: static PDFDoc GenerateGridPaperDoc(double, double, double, double, double red, double, double, double, double, double)
• New method: static PDFDoc GenerateLinedPaperDoc(double, double, double, double, double, double, double, double, double, double, double, double, double, double, double, double, double, double, double)
• New method: static PDFDoc GenerateGraphPaperDoc(double, double, double, double, double, int, double, double, double, double, double, double)
• New method: static PDFDoc GenerateMusicPaperDoc(double, double, double, int, double, double, double, double, double, double, double, double)
• New method: static PDFDoc GenerateDottedPaperDoc(double, double, double, double, double, double, double, double, double, double)
• New method: static PDFDoc GenerateIsometricDottedPaperDoc(double, double, double, double, double, double, double, double, double, double)

New class: OCRModule

• void OCRModule.ApplyOCRJsonToPDF(PDFDoc, string)
• void OCRModule.ApplyOCRXmlToPDF(PDFDoc, string)

New class: RectRedactionCreate

New class: TextRedactionCreate

New interface: IMeasure

New enum: PageUnit

New enum: MeasureInfoType

New class: MeasureInfo

New class: MeasureInfoGroup

New class: MeasureUtils

• New method: static void SetMeasurementInfo(IAnnot, IMeasure)
• New method: static void LoadMeasureInfoToObj(Obj, IMeasure)
• New method: static MeasureInfoGroup GetAnnotMeasureInfo(IAnnot)
• New method: static MeasureInfo GetMeasureIngo(Obj)
• New method: static bool IsRulerMeasure(IAnnot)
• New method: static bool IsAreaMeasure(IAnnot)
• New method: static bool IsPerimeterMeasure(IAnnot)
• New method: static string GetIT(IAnnot)
• New method: static string ConvertToFinalVal(double, string, string, string, string, string)
• New method: static double ConvScaleToPDFFactor(PageUnit, ToolType, string, string)
• New method: static double ConvStrToPDFPrecision(string)
• New method: static string ConvPDFPrecisionToStr(double)
• New method: static PageUnit GetPageUnitFromString(string)
• New method: static string FormatDecimals(double, string)
• New method: static double CalcPerimeter(List<Point>)
• New method: static double CalcArea(List<Point>)
• New method: static void UpdateAreaAnnot(Annots.Polygon)
• New method: static void UpdatePerimeterAnnot(Annots.PolyLine)

New class: RulerCreate

New class: AreaMeasureCreate

New class: PerimeterMeasureCreate

New class: AnnotEditAdvancedShape

New class: WindowsInfo

• New method: static WindowsInfo RetrieveApiInfo()

New enum: Build

New class: BooleanToBackgroundColorConverter

New class: BooleanToBrushConverter

New class: BooleanToMarginConverter

New class: BooleanToMaxLengthConverter

New class: BooleanToMaxWidthConverter

New class: BooleanToOpacityConverter

New class: BooleanToOpacityParamConverter

New class: BooleanToThicknessConverter

New class: DoubleToPointLabelConverter

New class: DoubleToThicknessConverter

New class: EmptyOrNullToVisibilityConverter

New class: EnumToBooleanConverter

New class: EnumToOpacityConverter

New class: IconToCustomUnicodeConverter

New class: IntEnumToBooleanConverter

New class: IntEnumToVisibilityConverter

New class: InverseBooleanToIntParameterConverter

New class: NotNullToBooleanConverter

New class: NotNullToVisibilityConverter

New class: RatioToPercentageConverter

New class: RatioToPercentageLabelConverter

New class: ReverseBooleanToBackgroundOpacityConverter

New class: ReverseBooleanToThicknessConverter

New class: ReverseSelectedToOpacityConverter

New class: SelectedIconToCustomUnicodeConverter

New class: SelectedToOpacityConverter

New class: StringToResourceConverter

New class: ThicknessToHalfPointConverter

New class: ToolTypeToBooleanConverter

New class: GreaterThanToOpacityConverter

New class: NumberToColumnNameConverter

New class: static DependencyObjectExtensions

New class: AsyncCommand

New class: AsyncCommandBase

New interface: IAsyncCommand

New class: NotifyTaskCompletion<TResult>

New class: RelayCommand<T>

New class: CheckedCommand

New class: CloseRequestedCommand

New class: FlyoutClosedCommand

New class: FlyoutOpenedCommand

New class: ItemClickCommand

New class: KeyDownCommand

New class: KeyUpCommand

New class: LoadedCommand

New class: LostFocusCommand

New class: PasswordChangedCommand

New class: PointerContactCommand

New class: PointerPressedCommand

New class: RightTappedCommand

New class: SelectionChangedCommand

New class: SizeChangedCommand

New class: TappedCommand

New class: TextChangedCommand
